Appearance
Standard
- Audio, Antenna - Fender Mounted
- Body Side Moldings – Carbon Black
- 50/50 Hinged Rear Door, 180-degree Opening (Regular Length)
- Sliding Passenger-Side Door
- Front License Plate Bracket
- Grille, Honeycomb Mesh Grille with Carbon Black Surround
- Auto High-Beam Headlamps
- Autolamp - Halogen Headlamps
- Mirrors Short Arm - Power Adjustment - Manual Folding
- Roof Marker Lamps
- Roof Marker Lamp Delete
- Low-Roof
- Rear Tow Hook
- Halogen Headlamps with Autolamp
Optional
- 50/50 Hinged Rear Door, 253-degree Opening (Long and Extended Length configurations)
- Front Bumper – Body Colored. Includes Front Fog Lamps
- Rear Bumper – Carbon Black, with integral step. Optional on Low Roof
- 60/40 Hinged Passenger-Side Door (Low Roof)
- Wheel Well Liners - Black (Front only)
- High-Intensity Discharge (HID) Headlamps
- Mirrors Short Arm - Power Adjusting, Manual-Folding Heated with Turn Signals
- Mirrors Long Arm - Power Adjusting, Manual-Folding
- Mirrors Long Arm - Power Adjusting, Manual-Folding Heated with Turn Signals
- Extended-Length Running Boards
- Autolamp - Includes Wiper Activated Halogen Headlamps
- Front Fog Lamps - Included in Reverse Sensing System and Front and Rear Split-View Camera
- Wiper Activated Headlamps
- Power Running Boards
- Medium-Roof
- High-Roof
Protection
Standard
- Windows – All-Around Fixed
Optional
- Remote Keyless-Entry Keypad
- Key - 2 additional (4 total) with key fobs
- MyKey®
- Egress Window - Only available with Windows-All-Around, Windows-All Around (Fixed)
- Egress Window - Includes Rear-window Defroster. Requires Windows-All-Around, Fixed and Privacy Glass
Windows & Glass
Standard
- Windows - Tinted Glass
- Windows - Rear Window
Optional
- Privacy Glass. Includes Rear-window Defroster
Climate
Standard
- Air Conditioning - Front and Rear
Optional
- Auxiliary Heater Prep Package without Rear Controls
- Auxiliary Heater / AC Prep Package without Rear Controls
Comfort and Convenience
Standard
- Horn - Single-Note Electric
- Rearview Mirror (when equipped with rear Glass)
- Headliner – Cloth, Full Length
- Console - Medium Center Console
- Post-Collison Braking
- Pre-Collision Assist with Automatic Emergency Braking (AEB)
- Lane-Keeping System
- Floor Covering, Vinyl, Front & Rear
- Glove Box (Locking)
- Instrumentation – Tachometer, Fuel Level and Coolant Temperature
- Interior Lighting
- Front Dome Lamp with Map Lights and Theater-Dimming
- A-Pillar Handles
- Two Auxiliary 12-Volt Powerpoints
- USB Ports – 5 amps
- Sun Visors - with Illuminated Vanity Mirror (Driver and Passenger)
- Automatic Rain-Sensing Wipers
- FordPass™ Connect
- Back Up Alarm
- B-Pillar Assist Handle (Passenger-side)
- Forward Collision Warning
- Headlamp Courtesy Delay
Optional
- Horn – Dual-Note
- Adaptive Cruise Control - Includes Adjustable Speed Limiting Device (ASLD)
- Blind Spot Information System (BLIS® ) with Cross-traffic Alert and Trailer Coverage. Includes Short-Arm Power, Power Folding Heated with Turn Signals
- Floor Covering, Carpet - Front & Rear
- Floor Covering - Vinyl
- Flooring, Carpet - Front Mats
- Vehicle Maintenance Monitor - Includes Engine Hour Meter
- High Capacity Upfitter Switches
- Upfitter Interface Module (UIM)
- Smoker’s Package – Cigarette lighter and ash cup
- Front and Rear Split-View Camera
- Reverse Sensing System. Included with Front and Rear Split-View Camera, Side Sensing System and Enhanced Active Park Assist
- Side Sensing System. Included with Front and Rear-View Camera and Enhanced Active Park Assist
- Passenger Van 130" W/B (LR,MR) GVWR 8550 lbs. SRW
- Passenger Van 148" W/B (LR,MR,HR) GVWR 9250 - 10360 lbs. SRW
- Auto Start-Stop Switch Delete Deletes button on dash which disables Auto Start-Stop Technology. Available on 3.5L EcoBoost® V6 only
- Front Overhead Shelf
Entertainment Systems
Standard
- AM/FM stereo with 4.0" multifunction display, Bluetooth, and Dual USB ports
Optional
- SYNC® 3 with 4.0" multi-function display, AM/FM stereo, Bluetooth and Dual USB ports
- HD/SiriusXM® capability, SYNC® 3 with 4.0" multifunction display, AM/FM stereo, Bluetooth, and Dual USB ports
- SYNC® 3 with 8.0" colored multi-function touch screen, AM/FM stereo, Bluetooth, and Dual USB ports
- HD/SiriusXM® capability, SYNC® 3 with 8.0" colored multi-function touch screen, AM/FM stereo, Bluetooth, audio input jack, and Dual USB ports
- Audio, AM/FM Stereo, SYNC® 3 With Navigation and 8" Color Multifunction Display Media Hub, HD Radio™ and SiriusXM® Radio Capability With Four Front Speakers
- 8 speakers (4 front/4 rear)
Seating
Standard
- Driver and Front-passenger Manual Reclining Bucket Seats with Adjustable Headrest (Includes driver-side and passenger-side inboard armrest)
- Ebony Cloth, 2-way manual Driver and 2-way manual Passenger seats
Optional
- 2-Passenger Seating. Optional with Long Length Passenger Van without Builders Prep Package
- 8-Passenger Seating. 1st row: 2 seats, 2nd row: 3 seats, 3rd row: 3 seats. Optional with Low Roof Regular Length Passenger Van
- 8 Passenger Seating. 1st row: 2 seats, 2nd row: 3 seats, 3rd row: 3 seats. Optional with Medium Roof Regular Length Passenger Van
- 8-Passenger Seating. 1st row: 2 seats, 2nd row: 3 seats, 3rd row: 3 seats. Optional with Long Length Passenger Van.Not available with Low Roof Passenger Van
- 10-Passenger Seating. 1st row: 2 seats, 2nd row: 2 seats, 3rd row: 3 seats, 4th row: 3 seats. Optional with Extended Length Passenger Van
- 12-Passenger Seating. 1st row: 2 seats, 2nd row: 3 seats, 3rd row: 3 seats, 4th row: 4 seats. Standard with Long Length Passenger Van
- 14-Passenger Seating. 1st row: 2 seats, 2nd row: 2 seats, 3rd row: 3 seats, 4th row: 3 seats, 5th row: 4 seats. Optional with Long Length Passenger Van. Optional with Passenger Van XL and XLT
- 14-Passenger Seating. 1st row: 2 seats, 2nd row: 2 seats, 3rd row: 3 seats, 4th row: 3 seats, 5th row: 4 seats. Optional with Extended Length Passenger Van
- 15-Passenger Seating. 1st row: 2 seats, 2nd row: 3 seats, 3rd row: 3 seats, 4th row: 3 seats, 5th row: 4 seats. Optional with Long Length Passenger Van
- Dark Palazzo Gray Vinyl, 2-way manual Driver and 2-way manual Passenger seats
- Dark Palazzo Gray Vinyl, 2-way manual Driver and 2-way manual Passenger seats with Passenger Armrest
- Ebony Cloth, 10-way power Driver and 10-way power Passenger seats. Cargo Van and Crew Van are not available with the combination of 9,400/9,500 GVWR and the 3.5L EcoBoost® V6 or 3.5L PDFi V6 engines
Packages
Standard
- Power Equipment Group (Power Locks and Windows) with Remote Keyless-Entry
Optional
- Modified Vehicle Wiring System
- Tow/Haul Mode with Trailer Wiring Provisions
- Remote Start
- Heavy-Duty Trailer Tow Package
- Builders Prep Package
Handling
Standard
- Electric Power Assisted Steering (EPAS)
- Tilt and Telescoping Steering Wheel
- Manual Parking Brake
- Suspension, Front - Independent MacPherson-strut, Stabilizer Bar
- Suspension, Rear - Leaf Springs, Heavy-duty Gas Shock Absorbers
- Heavy-Duty Front Axle
- AdvanceTrac® With RSC®
- Side Wind Stabilization
- Hill Start Assist
Optional
- Enhanced Active Park Assist
- Factory-Installed Integrated Trailer Brake Controller
- All-Wheel Drive
Power
Standard
- Auxiliary Fuel Port
- 3.5L PFDI V6
- 10-Speed Automatic Overdrive with SelectShift® . Auxiliary Transmission Oil Cooler is standard
- Fuel Tank – Capless fuel fill, 25 gallons (midship)
- Single Battery (70 amp-hr) 3.5L PFDi V6 engine only
- Single AGM Battery (70 amp-hr) Standard on 3.5L EcoBoost® V6 Engine Only
Optional
- Programmable Battery Guard/ Enhanced Cut-off Relay
- Dual Alternator – 250 amp (3.5L PFDi & 3.5L EcoBoost V6 only)
- Auxiliary Fuse Panel with High Spec Interface Connector
- 3.5L EcoBoost® V6
- Engine Block Heater (400W Rating)
- Extended Range Fuel Tank – Capless Fuel Fill, 31 U.S. gallons (midship)
- Single AGM Battery (70 amp-hr) Optional on 3.5L PDFi V6 Engine Only
- Dual AGM Batteries (70 amp-hr each) Optional on 3.5L EcoBoost® V6 and 3.5L PFDi V6 Engine
Wheels & Tires
Standard
- Tires, 195/75R16C 107/105 R BSW all-season (RWD with Standard Front Axle configurations only) - (DRW)
- Tires 205/75R16C 113/111 BSW all-season (AWD, 11,000 GVWR or RWD with Heavy-Duty Front Axle configurations only) - (DRW)
- Tires, 235/65R16 BSW all-season - (SRW)
- 16" Silver Steel Wheel With Black Hubcap (SRW)
- 16" Heavy-Duty Silver Steel Wheel With Exposed Lug Nuts (SRW)
- Full-Size Spare Tire and Wheel With Jack
- 16" Heavy-Duty Silver Steel Wheel With Exposed Lug Nuts (DRW)
Optional
- 16" Forged Aluminum Wheel (Heavy-Duty Front Axle configurations only). Available with Exterior Upgrade Package – SRW (Heavy-Duty Front Axle configurations only)
- 16" Heavy-Duty Forged Aluminum Wheel (Standard Front Axle configurations only). Available with Exterior Upgrade Package – DRW (Standard Front Axle configurations only)
- 16" Heavy-Duty Forged Aluminum Wheel (Heavy-Duty Front Axle configurations only). Available with Exterior Upgrade Package – DRW (Heavy-Duty Front Axle configurations only)
- 16-inch Black Steel Wheel with Gloss Black Center Caps (SRW)
- 16" Silver Aluminum Alloy Wheel (SRW)
- 16" Black Aluminum Alloy Wheel (SRW)
- 16" Heavy-Duty White Steel Wheel With Exposed Lug Nuts (Fleet Only)
- Spare Tire and Wheel Delete
- 16" Steel Wheel With Full Silver Wheel Cover (SRW)
- 16" Heavy-Duty Forged Aluminum Wheel (DRW)
Safety
Standard
- Tire Pressure Monitoring System (TPMS)
- Airbags – Driver and Passenger
- Brakes - 4 Brakes – 4-wheel Anti-lock Disc Brakes
- Safety belts - 3-point, all positions
- Safety Canopy® Side-Curtain Airbags
- SOS Post-Crash Alert System™ (distress call w/airbag deployment when ordered with SYNC)
Security
Standard
- Door Locks, Autolocking Drive Away with Crash Unlocking. Not available with Manual Locks
- SecuriLock® Passive Anti-Theft System (PATS) with engine immobilizer
- Rear View Camera With Trailer Hitch Assist
Exterior Dimensions
| 2021 Transit Passenger Van | ||||||
| Length (Regular, Long, Long-EL) | Regular | Regular | Long | Long | Long | Long-EL |
| Roof (Low, Medium, High) | Low | Medium | Low | Medium | High | High |
| [in.] | [in.] | [in.] | [in.] | [in.] | [in.] | |
| Wheelbase | 129.9 | 129.9 | 147.6 | 147.6 | 147.6 | 147.6 |
| Length | 219.9 | 217.8 | 237.6 | 235.5 | 235.5 | 263.9 |
| Height | 82.2 | 98.7 | 82.4 | 99.2 | 108.6 | 107.7 |
| Width - Excluding Mirrors (SRW/DRW) | 81.3 | 81.3 | 81.3 | 81.3 | 81.3 | 81.3 |
| Width - Including Mirrors | 97.4 | 97.4 | 97.4 | 97.4 | 97.4 | 97.4 |
| Width - Mirrors Folded | 83.2 | 83.2 | 83.2 | 83.2 | 83.2 | 83.2 |
| Front Track | 68.2 | 68.2 | 68.2 | 68.2 | 68.2 | 68.2 |
| Rear Track | 68.6 | 68.6 | 68.6 | 68.6 | 68.6 | 68.6 |
| Front Overhang | 40.3 | 40.3 | 40.3 | 40.3 | 40.3 | 40.3 |
| Rear Overhang | 49.7 | 47.6 | 49.7 | 47.6 | 47.6 | 70.6 |
| Load Height (Curb) | 28.2 | 28.2 | 28.8 | 28.8 | 28.8 | 27.8 |
| Side Cargo Door Opening Height | - | - | - | - | - | - |
| Side Cargo Door Opening Width - Hinged | - | - | - | - | - | - |
| Side Cargo Door Opening Width - Sliding | - | - | - | - | - | - |
| Rear Cargo Door Opening Height | 46.9 | 62.8 | 46.9 | 62.8 | 72.2 | 72.2 |
| Rear Cargo Door Opening Width | 59.8 | 59.8 | 59.8 | 59.8 | 59.8 | 59.8 |
Interior Dimensions
| 2021 Transit Passenger Van | ||||||
| Length (Regular, Long, Long-EL) | Regular | Regular | Long | Long | Long | Long-EL |
| Roof (Low, Medium, High) | Low | Medium | Low | Medium | High | High |
| [in.] | [in.] | [in.] | [in.] | [in.] | [in.] | |
| Head Room - First Row | 40.8 | 52.0 | 40.8 | 52.0 | 56.6 | 56.6 |
| Head Room - Second Row (where applicable) | 41.1 | 55.8 | 41.1 | 55.8 | 65.2 | 65.2 |
| Head Room - Third Row (where applicable) | 40.6 | 55.8 | 40.6 | 55.8 | 65.2 | 65.2 |
| Head Room - Fourth Row (where applicable) | 38.7 | 55.8 | 38.7 | 55.8 | 65.2 | 65.2 |
| Head Room - Fifth Row (where applicable) | - | - | 38.1 | 52.6 | 61.3 | 61.3 |
| Leg Room - First Row (Max.) | 41.3 | 41.3 | 41.3 | 41.3 | 41.3 | 41.3 |
| Leg Room - Second Row (where applicable) | 33.7 | 33.7 | 33.7 | 33.7 | 33.7 | 33.7 |
| Leg Room - Third Row (where applicable) | 35.6 | 35.6 | 35.6 | 35.6 | 35.6 | 35.6 |
| Leg Room - Fourth Row (where applicable) | 35.6 | 35.6 | 35.6 | 35.6 | 35.6 | 35.6 |
| Leg Room - Fifth Row (where applicable) | - | - | 35.6 | 35.6 | 35.6 | 35.6 |
| Hip Room - First Row | 60.7 | 60.7 | 60.7 | 60.7 | 60.7 | 60.7 |
| Hip Room - Second Row (where applicable) | 69.6 | 69.6 | 69.6 | 69.6 | 69.6 | 69.6 |
| Hip Room - Third Row (where applicable) | 67.3 | 67.3 | 67.3 | 67.3 | 67.3 | 67.3 |
| Hip Room - Fourth Row (where applicable) | 68.0 | 68.0 | 68.0 | 68.0 | 68.0 | 68.0 |
| Hip Room - Fifth Row (where applicable) | - | - | 68.0 | 68.0 | 68.0 | 68.0 |
| Shoulder Room - First Row | 67.9 | 67.9 | 67.9 | 67.9 | 67.9 | 67.9 |
| Shoulder Room - Second Row (where applicable) | 71.4 | 71.4 | 71.4 | 71.4 | 71.4 | 71.4 |
| Shoulder Room - Third Row (where applicable) | 67.0 | 67.0 | 67.0 | 67.0 | 67.0 | 67.0 |
| Shoulder Room - Fourth Row (where applicable) | 67.8 | 67.8 | 67.8 | 67.8 | 67.8 | 67.8 |
| Shoulder Room - Fifth Row (where applicable) | - | - | 67.8 | 67.8 | 67.8 | 67.8 |
| Cargo Length Front (at Floor) | 124.0 | 124.0 | 141.7 | 141.7 | 141.7 | 170.2 |
| Cargo Length Front (at Belt) | 115.1 | 115.1 | 132.8 | 132.8 | 132.8 | 161.3 |
| Cargo Width Between Wheelhouse (SRW/DRW) | 53.7 | 53.7 | 53.7 | 53.7 | 53.7 | 53.7 |
| Cargo Height Maximum | 52.8 | 67.6 | 52.8 | 67.6 | 77.0 | 77.0 |
Capacities
| 2021 Transit Passenger Van | ||||||
| Length (Regular, Long, Long-EL) | Regular | Regular | Long | Long | Long | Long-EL |
| Roof (Low, Medium, High) | Low | Medium | Low | Medium | High | High |
| Cu. ft. | Cu. ft. | Cu. ft. | Cu. ft. | Cu. ft. | Cu. ft. | |
| Cargo Volume Behind First Row (range) | 224.5 | 292.7 | 223.5 - 256.4 | 303.1 - 336.1 | 349.6 - 382.6 | 425.4 - 461.9 |
| Cargo Volume Behind Second Row (range) | 140.5 - 151.8 | 186.6 - 197.9 | 138.7 - 171.7 | 195.5 - 228.5 | 240.1 - 273.0 | 313.1 |
| Cargo Volume Behind Third Row (range) | 94.2 | 125.0 | 91.5 - 124.5 | 133.9 - 166.9 | 157 - 190 | 230.0 |
| Cargo Volume Behind Fourth Row (range) | 39.1 | 51.8 | 48.9 - 70.1 | 72.8 - 93.9 | 85.8 - 107 | 184.0 |
| Cargo Volume Behind Fifth Row | - | - | 15.3 | 20.5 | 23.4 | 100.5 |
Engine Capacities
| Engine type | 3.5L PFDi V6 | 3.5L EcoBoost® V6 |
| Displacement (cu. In../ ml) | 213/3,497 | 213/3,497 |
| Horsepower (SAE net @ RPM) | 275 @ 6,500 | 310 @ 5,000 |
| Torque (lb.-ft. @ RPM) | 262 @ 3,750 | 400 @ 2,500 |
| Compression ratio | 11.8.1 | 10.0:1 |
| Bore x stroke (in.) | 3.64 x 3.41 | 3.64 x 3.41 |
| Valvetrain | DOHC, 4 valve per cylinder | DOHC, 4 valve per cylinder |
| Fuel delivery | Sequential multiport electronic | Direct gasoline injection, dual turbochargers |
| Transmission type | 10-speed automatic Selectshift® with overdrive | 10-speed automatic Selectshift® with overdrive |
| Engine block material | Aluminum | Aluminum |
| Cylinder head material | Aluminum | Aluminum |
| *90% of peak torque available in the 1,500 - 2,500 rpm range |
Chassis Specifications
| Front suspension | Independent MacPherson-strut |
| Rear suspension | Leaf springs |
| Shock absorbers | Heavy-duty gas |
| Brakes | 4-wheel anti-lock disc brakes |
| Steering | Electric Power Steering (EPS) |
Passenger Van Capacities
| 2021 Transit Passenger Van | ||||||
| Length (Regular, Long, Long-EL) | Regular T-150 | Regular T-150 | Long T-350 | Long -T-350 | Long T-350 | Long-EL T-350HD |
| Roof (Low, Medium, High) | Low | Medium | Low | Medium | High | High |
| Seating (refer to Seating Chart) | 2, 8, 10 | 2, 5, 8, 10 | 2, 12, 14, 15 | 2, 8, 12, 14, 15 | 2, 8, 12, 14, 15 | 2, 10, 14, 15 |
| GVWR (range) lbs. | 8,550 | 8,550 | 9,250 - 9,550 | 9,250 - 9,550 | 9,250 - 9,550 | 10,360 |
| GCWR (range) lbs. | 10,800 | 10,800 | 10,800 - 11,200 | 10,800 - 11,200 | 10,800 - 11,200 | 10,800 - 11,200 |
| Maximum Towing Capability (when properly equipped) lbs. | 4,600 | 4,400 | 4,500 | 4,400 | 4,300 | 3,700 |
| Maximum Payload (for base configuration) lbs. | 2,860 | 2,670 | 3,230 | 3,090 | 2,950 | 3,340 |
Vehicle Highlights
| Fuel Capacity (Standard) | 25 gallons (midship) |
| Fuel Capacity (Optional) | 31 gallons (midship) |
| Drive Type | RWD/ DRW |
| Available Engines |
3.5L PFDi V6 |
| Horsepower | 275 HP @ 6,500 RPM |
| Torque | 262 lbs- ft @ 3,750 RPM |
| Available Engines |
3.5L EcoBoost® V6 |
| Horsepower | 310 HP @ 5,000 RPM |
| Torque | 400 lbs-ft @ 2,500 RPM |
| Transmission | 10-speed automatic |
| Selectshift® with overdrive | |
| Wheelbase | 130″ |
| 148″ | |
| Roof Height | Low |
| Medium | |
| High | |
| Length | Regular |
| Long | |
| Long-EL | |
| Maximum Seating Capacity | 15 Passengers |
| Maximum GVWR | 10,360 lbs. |
| Warranty | Bumper to Bumper: 3 years / 36,000 miles |
| Powertrain: 5 years / 60,000 miles | |
| Safety Restraint System: 5 years / 60,000 miles | |
| Corrosion (Perforation Only): 5 years / Unlimited miles | |
| Roadside Assistance Program: 5 years / 60,000 miles |
